TR-150SS-15
Product Features
| Volts | 12, 13, 14, 15 |
| Wattage | 150 watts |
| Max Amps | 1.25 amps |
| Dimensions | 11 3/4" L x 6" W x 5 1/2" D |
| Weight | 15 lbs |
Product Description
Multi-Tap Transformers
Construction: 304 Stainless Steel
Taps: 12-15 Volt Transformers are 12, 13, 14 & 15
Taps: 12-22 Volt Transformers are 12, 13, 14, 15, 16, 17, 18, 20, & 22
Primary Protection: Automatic thermal reset breaker
Secondary Protection: 25 amp, 300 watt magnetic breaker with reset switch
Torodial Core: Epoxy sealed core which is silent and up to 10% more efficient, runs much cooler than laminated cores
Terminal: Extra large 125 amp terminal blocks, holds (8) 12/2 wire
Internal Wiring: Non-corrosive, tin coated marine grade, dedicated current loop to measure primary amperage.
Timer Receptacle: Standard receptacle for plug and play options
Photo Cell Plug: Dedicated plug for easy installation of photo cell
Child Proof Safety: Lockable latched door to prevent access
